PDXpert PLM software system requirements

The PDXpert product lifecycle management system consists of three major components:

  • One or more clients that execute the application business rules and provide the user experience.
  • An application server that fulfills client requests for product data and file library transactions, and performs data indexing and maintenance functions.
  • A SQL Server database server that contains your product data.

In a single-user installation, all of these components are installed on one computer. Most installations, however, will have one computer act as the database and file management server, and other computers act as clients. Servers do not have to be dedicated exclusively to PDXpert PLM software, although sharing resources with other applications and functions may affect system performance.

The PDXpert installer automatically detects your Windows 32-bit or 64-bit operating system and installs the appropriate executable. PDXpert can be run in a mixed network of 32-/64-bit computers.

System (server & local client) computer

These are the minimum requirements for operating PDXpert and its SQL Server database on a dedicated machine with up to about ten users. Consider improving the system configuration when also supporting other software applications; services such as encryption, VPN and antivirus; and/or more than ten users.

Hardware Requirements
Processor 32-bit: 2 GHz or higher (dual-core recommended)
64-bit: 2 GHz or higher
Memory (RAM) SQL Server LocalDB or Express: 2 GB or higher
SQL Server Workgroup or higher: 4 GB or higher
Hard disk space 6 GB of available space on an uncompressed local disk1. The database will grow as you add PDXpert PLM product data objects; allow at least 10 GB. Additional space will be required for the uncompressed file library2. Do not install on a compressed, network-mapped, or external (e.g., USB) disk.
Video display Minimum 1280x1024. Windows scaling should be set to 100% for proper viewing.
Operating system: Supported edition(s)3 32-bit 64-bit .NET Framework4
Windows Server 2012 R2: all Editions Yes 4.5.1
Windows Server 2012: all Editions Yes 4.5.1
Windows Server 2008 R2: all Editions5 SP1 4.5.1
Windows Server 2008: all Editions5 SP2 SP2 4.5.1
Windows 10: Home (for single user), Professional, Enterprise Yes Yes 4.5.1
Windows 8 & 8.1: Standard, Professional, Enterprise Yes Yes 4.5.1
Windows 7: Professional, Enterprise, Ultimate5 SP1 SP1 4.5.1
Database engine6 Use
SQL Server Supported Versions 2008 SP47; 2008 R2 SP37; 2012 SP3; 2014 SP2; 2016
SQL Server LocalDB or Express Edition Up to about 10 user accounts8
SQL Server Workgroup, Standard or Enterprise Edition All user accounts

Network client computer

Hardware Requirements
Processor 32-bit: 2 GHz or higher
64-bit: 2 GHz or higher
Memory (RAM) 1 GB or higher
Hard disk space Up to 650 MB for application and data cache within user's %LocalAppData% folder (usually the C: drive). Do not install on a compressed, network-mapped or external (e.g., USB) disk.
Video display Minimum 1280x1024. Windows scaling should be set to 100% for proper viewing.
Operating system: Supported edition(s)3 32-bit 64-bit .NET Framework4
Windows Server 2012 R2: all Editions Yes 4.5.1
Windows Server 2012: all Editions Yes 4.5.1
Windows Server 2008 R2: all Editions5 SP1 4.5.1
Windows Server 2008: all Editions5 SP2 SP2 4.5.1
Windows 10: Home, Professional, Enterprise Yes Yes 4.5.1
Windows 8 & 8.1: Standard, Professional, Enterprise Yes Yes 4.5.1
Windows 7: Home Premium, Professional, Enterprise, Ultimate5 SP1 SP1 4.5.1

Notes

  1. The SQL Server installer creates temporary files on the system (typically C:) drive. Verify that you have 4 GB or 6 GB of available disk space on the system drive for these files. Even when installing to a non-system drive, SQL Server requires significant space on the system drive.
  2. Files are stored in a separate PDXpert library folder under Windows, with their metadata in the database.

  3. Our releases are tested for compatibility on Windows US-English using the latest service packs and updates. Verify compatibility with your localized Windows language and regional settings. Follow our recommendations to minimize incompatibilities between network devices, DNS services, operating systems and local languages, machine names and the workgroup or domain name.

  4. The minimum .NET Framework required for operation. Always apply the latest .NET service pack.
  5. Microsoft ended mainstream support for Windows 7, Windows Server 2008 and Windows Server 2008 R2 in January 2015. Current PDXpert releases are not compatible with Windows XP, Windows Server 2003, and Windows Vista. Use a supported operating system to ensure compatibility with PDXpert.

  6. The PDXpert system setup file automatically downloads and installs Microsoft SQL Server Express LocalDB. Any other SQL Server engine requires separate installation as described in the PDXpert PLM Software Installation Guide.

  7. Microsoft ended mainstream support for SQL Server 2008 and SQL Server 2008 R2 in July 2015. Microsoft has ended all support for SQL Server 2005. Use a supported database engine to ensure compatibility with PDXpert software.

  8. Per Microsoft guidelines. PDXpert increases efficiency by pooling database connections, so this value is not an absolute upper limit. The number of users that a specific SQL Edition supports will depend on factors such as concurrent use, client activities, network bandwidth and utilization, encryption, product data complexity, hardware configurations, and other server applications. Contact us for specific recommendations.

We rely upon technologies from Microsoft and other suppliers that are constantly evolving. Always use Microsoft's supported versions of Windows, .NET and SQL Server. Always apply the latest available service packs and updates. All hardware and software requirements and supported configurations are subject to change without notice. Updated 2016-08-16.
